FLTA2
Our flagship coilover setup. The FLT-A2 features a light weight, 15 way adjustable monotube damper that ensures high strength and fade free performance. The ride height is adjustable separate from the spring perch giving you maximum suspension travel at any setting. This also allows for proper corner weighting of the vehicle without effecting spring preload settings.
| JIC FLT-A2 SUSPENSION KIT
|
| Model |
Type |
Year |
F/R |
| ACURA |
|
|
|
| Integra |
DC2 |
94~01 |
10kg/7kg |
| NSX |
NA1 |
91~ |
9kg/10kg |
| RS-X |
DC5 |
02~ |
8kg/9kg |
| HONDA |
|
|
|
| Accord |
CG |
98~ |
9kg/6kg |
| Civic/Del-Sol |
EG |
92~95 |
9kg/6kg |
| Civic |
EK |
96~00 |
9kg/6kg |
| |
EP/ES |
01~ |
8kg/9kg |
| Prelude |
BB6 |
97~ |
10kg/7kg |
| S2000 |
AP1 |
99~ |
|
| INFINITI |
|
|
|
| I30 |
A32 |
96~99 |
9kg/6kg |
| |
A33 |
00~ |
9kg/6kg |
| G35 |
V35
2door |
02~ |
10kg/10kg |
| |
V35
4door |
02~ |
|
| LEXUS |
|
|
|
| ES300 |
MCV20L |
97~01 |
8kg/6kg |
| GS300/400 |
JZS147 |
93~97 |
14kg/10kg |
| |
JZS161 |
98~ |
14kg/10kg |
| LS400 |
UCF10/20 |
|
|
| IS300 |
JCE10L/SXE10 |
01~ |
14kg/10kg |
| SC300/400 |
JZZ30 |
92~99 |
14kg/10kg |
| MAZDA |
|
|
|
| Miata |
NA6C |
89~96 |
9kg/8kg |
| |
NB8C |
98~ |
9kg/8kg |
| Protegé |
BJFP |
99~ |
7kg/4kg |
| RX-7 |
FC3S |
87~92 |
8kg/6kg |
| |
FD3S |
93~95 |
12kg/9kg |
| RX8 |
|
04- |
10k/10k |
| Mazda 6 |
|
03- |
9k/6k |
| MITSUBISHI |
|
|
|
| 3000GT |
Z11A
(FF) |
90~99 |
14kg/9kg |
| |
Z16A
(AWD) |
14kg/10kg |
| Eclipse |
D22A
(FF) |
89~94 |
8kg/5kg |
| |
D27A
(AWD) |
9kg/6kg |
| |
D32A |
95-99 |
9kg/7kg |
| |
D52/53A |
00~ |
8kg/5kg |
| Garant |
E39A* |
89~92 |
8kg/6kg |
| |
EA8A* |
99~ |
8kg/5kg |
| Lancer |
CS6A |
01~ |
8kg/5kg |
| Lancer Evo 1/2/3 |
CD/E9A* |
92~95 |
7kg/6kg |
| Lancer Evo 4 |
CN9A* |
96~97 |
7kg/7kg |
| Lancer Evo 5/6 |
CP9A* |
98~00 |
8kg/7kg |
| Lancer Evo 7/8 |
CT9A* |
01~ |
8kg/7kg |
| Mirage |
CA4A* |
91~95 |
7kg/5kg |
| |
CJ4A* |
96~ |
7kg/5kg |
| NISSAN |
|
|
|
| 240SX |
S13 |
89~94 |
8kg/6kg |
| |
S14 |
95~98 |
8kg/6kg |
| 300ZX |
Z32 |
90~96 |
12kg/8kg |
| 350Z |
Z33 |
03~ |
10kg/12kg |
| Altima |
|
01~ |
|
| Maxima |
A32 |
96~99 |
9kg/6kg |
| |
A33 |
00~ |
9kg/6kg |
| Sentra |
B15 |
00~ |
7kg/5kg |
| Skyline GT-R |
R32* |
89~94 |
12kg/9kg |
| |
R33* |
95~98 |
12kg/10kg |
| |
R34* |
99~ |
12kg/10kg |
| SCION |
|
|
|
| xA |
|
03- |
|
| xB |
|
03- |
|
| SUBARU |
|
|
|
| Impreza |
GC6/8 |
98~01 |
7kg/5kg |
| |
GDA |
02~ |
7kg/5kg |
| Legacy |
BD5* |
95~99 |
8kg/5kg |
| |
BE5 |
00~ |
8kg/6kg |
| Forester |
SG5 |
|
7kg/5kg |
| TOYOTA |
|
|
|
| Camry / Solara |
MCV20L |
97~ |
8kg/6kg |
| Celica |
ZZT231 |
00~ |
6kg/8kg |
| Corolla |
AE92* |
87~92 |
7kg/5kg |
| |
AE101* |
93~97 |
7kg/5kg |
| |
ZZE110* |
98~ |
7kg/5kg |
| Matrix |
ZZE133L |
02~ |
6kg/8kg |
| MR-2 |
SW20 |
91~ |
5kg/8kg |
| MR-2
Spider |
ZZW30 |
01~ |
4kg/7kg |
| Supra |
JZA70 |
87~92 |
14kg/10kg |
| |
JZA80 |
93~98 |
14kg/10kg |
FLTA2-RS
The FLTA2-RS has all of the great features of the normal FLTA2, but is custom tuned to the racer's needs on a case by case basis. Drag racers, road racers and even autocrossers will benefit from our custom tuned suspension. Price dependant on necessary configurations (i.e.. extra helper springs or very heavy spring rates.)
| JIC
FLT-A2RS SUSPENSION KIT |
| Model |
Type |
Year |
F/R |
| ACURA |
|
|
|
| Integra |
DC2 |
94~01 |
14kg/12kg |
| NSX |
NA1 |
91~ |
12kg/16kg |
| HONDA |
|
|
|
| Civic/Del-Sol |
EG |
92~95 |
14kg/12kg |
| Civic |
EK |
96~00 |
14kg/12kg |
| Prelude |
BB6 |
97~ |
14kg/10kg |
| S2000 |
AP1 |
99~ |
16kg/14kg |
| INFINITI |
|
|
|
| G35 2door |
|
02~ |
16kg/18kg |
| LEXUS |
|
|
|
| IS300 |
JCE10L/SXE10 |
01~ |
16kg/12kg |
| MAZDA |
|
|
|
| Miata |
NA6C |
89~96 |
12kg/12kg |
| |
NB8C |
98~ |
12kg/12kg |
| Protegé |
BJFP |
99~ |
12kg/8kg |
| RX-7 |
FC3S |
87~92 |
14kg/12kg |
| |
FD3S |
93~95 |
16kg/16kg |
| MITSUBISHI |
|
|
|
| 3000GT |
Z11A
(FF) |
90~99 |
18kg/14kg |
| |
Z16A
(AWD) |
18kg/16kg |
| Eclipse |
D22A
(FF) |
89~94 |
12kg/8kg |
| |
D27A
(AWD) |
12kg/10kg |
| |
D32A |
95-99 |
12kg/10kg |
| |
D52/53A |
00~ |
12kg/8kg |
| Lancer Evo 1/2/3 |
CD/E9A* |
92~95 |
2kg/8kg |
| Lancer Evo 4 |
CN9A* |
96~97 |
12kg/12kg |
| Lancer Evo 5/6 |
CP9A* |
98~00 |
14kg/12kg |
| Lancer Evo 7 |
CT9A* |
01~ |
16kg/14kg |
| Mirage |
CA4A* |
91~95 |
12kg/8kg |
| |
CJ4A* |
96~ |
12kg/8kg |
| NISSAN |
|
|
|
| 240SX |
S13 |
89~94 |
14kg/10kg |
| |
S14 |
95~98 |
14kg/10kg |
| 300ZX |
Z32 |
90~96 |
18kg/14kg |
| 350Z |
Z33 |
03~ |
16kg/18kg |
| Sentra |
B15 |
00~ |
12kg/8kg |
| Skyline GT-R |
R32* |
89~94 |
16kg/12kg |
| |
R33* |
95~98 |
16kg/14kg |
| |
R34* |
99~ |
16kg/14kg |
| SUBARU |
|
|
|
| Impreza |
GC6/8 |
98~01 |
12kg.8kg |
| |
GDA |
02~ |
12kg/9kg |
| TOYOTA |
|
|
|
| Celica |
ZZT231 |
00~ |
10kg/12kg |
| Corolla |
AE92* |
87~92 |
12kg/9kg |
| |
AE101* |
93~97 |
12kg/9kg |
| MR-2 |
SW20 |
91~ |
8kg/12kg |
| MR-2
Spider |
ZZW30 |
01~ |
7kg/10kg |
| |
JZA80 |
93~98 |
18kg/14kg |
SF-1
Our entry level suspension. Features adjustable ride height and a fixed rate damper. For those that wish to lower their ride, but don't feel the need to adjust dampers. Includes upper pillow ball mounts. MacPherson strut designs benefit from front camber adjustability.
| JIC SF-1 SUSPENSION KIT |
| Model |
Type |
Year |
F/R |
| ACURA |
|
|
|
| Integra |
DC2 |
94~01 |
8kg/5kg |
| Legend |
KA7* |
91~95 |
12kg/8kg |
| HONDA |
|
|
|
| Accord |
CD* |
94~97 |
8kg/5kg |
| |
CG |
98~ |
8kg/5kg |
| Civic/CRX |
EF* |
88~91 |
7kg/5kg |
| Civic/del-sol |
EG |
92~95 |
7kg/5kg |
| Civic |
EK |
96~00 |
7kg/5kg |
| INFINITI |
|
|
|
| G20 |
HP10 |
91~96 |
8kg/5kg |
| |
HP11 |
97~ |
8kg/5kg |
| I30 |
A32 |
96~99 |
8kg/6kg |
| Q45 |
G50* |
94~96 |
10kg/8kg |
| |
Y33* |
97~00 |
8kg/7kg |
| LEXUS |
|
|
|
| ES300 |
MCV20L |
97~01 |
7kg/5kg |
| GS300/400 |
JZS147 |
93~97 |
12kg/9kg |
| |
JZS161 |
98~ |
12kg/9kg |
| IS300 |
JCE10L/SXE10 |
01~ |
12kg/9kg |
| LS400 |
UCF10/UCF20* |
91~96 |
12kg/9kg |
| SC300/400 |
JZZ30 |
92~99 |
12kg/9kg |
| MAZDA |
|
|
|
| Miata |
NA6C |
89~96 |
9kg/8kg |
| |
NB8C |
98~ |
9kg/8kg |
| RX-7 |
FC3S |
87~92 |
7kg/5kg |
| |
FD3S |
93~95 |
10kg/7kg |
| MITSUBISHI |
|
|
|
| Diamante |
F15A* |
92~96 |
9kg/6kg |
| Eclipse |
D32A |
95~99 |
8kg/6kg |
| Garant |
E39A* |
89~92 |
7kg/5kg |
SA-1
Adjustable street suspension. Features adjustable ride height and a five way adjustable damper. Includes upper pillow ball mounts. MacPherson strut designs benefit from front camber adjustability.
| JIC
SA-1 SUSPENSION KIT |
|
|
| |
Type |
Year |
F/R |
| INFINITI |
|
|
|
| G20 |
HP10* |
91~96 |
8kg/5kg |
| |
HP11* |
97~ |
8kg/5kg |
| Q45 |
Y33* |
97~00 |
10kg/8kg |
| LEXUS |
|
|
|
| LS400 |
UCF10/20* |
91-00 |
12kg/9kg |
| MITSUBISHI |
|
|
|
| Diamante |
F15A* |
92~96 |
9kg/6kg |
| |
|
|
|
| SUBARU |
|
|
|
| Legacy |
BC5* |
90-94 |
7kg/5kg |
| TOYOTA |
|
|
|
| Celica |
ST183
(FF)* |
90~93 |
7kg/5kg |
| |
ST185
(AWD)* |
90~93 |
7kg/5kg |
| Corolla |
AE86* |
83~86 |
7kg/
- |
|
