TEIN Type BASIC damper is for the driver that is seeking high performance with a reasonable price. The Basic damper MSRP starts at $750.00, which includes 4 springs and 4 shocks. Compared to the "sleeve type" coil over, the Type Basic has a more exclusive set up for a better balance of suspension travel and damping force.
* High performance and cost effective.
* Ride Height adjustable.
* New paint coating for rust prevention.
* Pillow ball mounts are optional (on certain applications).
* Exclusive design for USA vehicle specifications.
(only available for the U.S.A Market).
* Available for overhaul.
Contents of damper kit
Height Adjustable shock absorber x4, Main spring x4
Lower spring seat x4, Seat lock x4, Thrust washer x4
Bump rubber x4, Dust cover x4
Hook spanner x2, Instruction manual
*Strut suspension comes with upper spring seat. |
| Make |
Model |
Year |
| Body |
| |
| |
| ACURA |
Integra |
90-93 |
| DA9 |
| ACURA |
Integra |
94-01 |
| DC2/4(not
Type-R) |
| ACURA |
3.2
TL |
99+ |
| UA5 |
| ACURA |
3.2
CL |
01+ |
| YA4 |
| HONDA |
Accord |
90-93 |
| CB7 |
| HONDA |
Accord |
94-97 |
| CD5/7 |
| HONDA |
Accord |
98-02 |
| CG1/2/3 |
| HONDA |
Civic |
89-91 |
| EF9 |
| HONDA |
CRX |
89-91 |
| ED8/9 |
| HONDA |
Civic |
92-95 |
| EH2/3 |
| HONDA |
Del
Sol |
93-97 |
| EG1 |
| HONDA |
Civic |
96-00 |
| EM1,EJ6/7/8 |
| HONDA |
Civic |
01+ |
| EM2/ES1 |
| HONDA |
Civic
Si |
03+ |
| EP3 |
| HONDA |
Prelude |
92-96 |
| BB1/2 |
| HONDA |
Prelude |
97+ |
| BB6 |
| INFINITI |
G35
Sedan |
03+ |
| V35 |
| INFINITI |
G35
Coupe |
03+ |
| V35 |
| MITSUBISHI |
Eclipse
(2WD) |
95-99 |
| D32A |
| MITSUBISHI |
Eclipse
(AWD) |
95-99 |
| D38A |
| MITSUBISHI |
Eclipse |
00+ |
| D53A |
| MITSUBISHI |
Lancer
EVO VII/VIII |
01+ |
| CT9A |
| NISSAN |
240SX |
89-94 |
| S13 |
| NISSAN |
240SX |
95-98 |
| S14 |
| NISSAN |
200SX |
95-98 |
| B14 |
| NISSAN |
350Z |
03+ |
| Z33 |
| NISSAN |
Sentra |
95-98 |
| B14 |
| NISSAN |
Sentra
SE-R |
02+ |
| B15 |
| TOYOTA |
Celica |
00+ |
| ZZT231 |
|
TEIN has developed advanced technology to design the shell case and stroke to bring out the full potential of your vehicle.
These features of the TEIN Super Street Damper kit were designed with greater performance to satisfy all your driving demands. This high performance damper can be used for weekend racing and/or daily driving.
The discomfort caused by uneven roads or bumps are eliminated on daily street use. For race use, the ride height adjustable system enables you to adjust ride height and 16 levels of damping force.
In other words, you can set your vehicle to meet all situations!
* High performance and cost effective.
* 16 levels of damping force adjustment (compression and rebound together).
* Ride height adjustable.
* New paint coating for rust prevention.
* Pillow ball mounts are optional (on certain applications).
* Exclusive design for USA vehicle specifications (only available for the U.S.A Market).
* Available for overhaul.
Contents of damper kit
Adjustable shock absorber x4, Main spring x4
Lower spring seat x4, Seat lock x4, Thrust washer x4
Bump rubber x4, Dust cover x4
Hook spanner x2, Instruction manual
*Strut suspension comes with upper spring seat.
____________
| Damping force adjustment
16 level damping adjustment
High performance and cost effective.
Sport handling and driving comfort combined.
TEIN has developed advanced technology to design the shell case and stroke to bring out the full potential of your vehicle. The features of the TEIN Super Street Damper were designed with greater performance to satisfy all your driving demands. This high performance damper can be used for weekend racing and/or daily driving. The discomfort caused by uneven roads or bumps are eliminated on daily street use. For race use, the ride height adjustable system enables you to adjust ride height and 16 levels of damping force. In other words, you can set your vehicle to meet all situations! |
|
TEIN Type FLEX damper kit was designed to provide driving comfort and sports performance with its full-length adjustment system. We have incorporated separate height and preload adjustments, which allows you to have various set-ups to meet different road conditions. The FLEX Damper kit includes pillow ball upper mounts and is compatible with the EDFC, for maximum performance for the streets.
* Full-length adjustment and height adjustment for separate setting of the height and spring preload.
* 16 levels of damping force adjustment (compression and rebound together).
* Teflon coating for rust prevention.
* Newly designed spring seat and spring seat lock for easy height adjusting.
* Pillow ball upper mounts are included.
* Compatible with EDFC.
* Available for overhaul.
Contents of damper kit
Adjustable shock absorber x4, Main spring x4
Lower spring Seat x4,Spring Seat lock x12
Bump rubber x4, Dust cover x4
Hook spanner x2, Instruction manual
*Strut suspension comes with upper spring seat. |
EDFC (Electronic Damping Force Controller) makes it possible for the driver to control the damping force by controlling a motor installed in the shock absorber while being seated in the driver's seat. Since the damping force can be manually controlled with ease to meet different situations, the driver can enjoy variations in the suspension setting.
EDFC is developed based on the following concepts:
1. Easily controlled from the inside
To control the damping force, the driver does not need to raise the hood or take off rear interior parts such as the speaker board or rear seat. All a driver is required to do is simply operate a button while being seated in the driver's seat.
According to the marketing research we have carried out, EDFC is always ranked high on the 'want list'. Therefore, it has grown from overwhelming customer demand, specifically from requests by customers who have purchased damping-force-control-type shock absorbers, or who intend to purchase shock absorbers made by TEIN Inc.
2. Memory contents easily recalled
EDFC can store in its memory up to three types of damping force levels which have been set up according to various situations, and is equipped with a memory recall function. With the touch of a button, the driver can set the damping force level to his/her preference in various modes such as a normal driving mode when going out with family, a sports mode when enjoying a winding road alone, and a cruising mode when driving on a freeway. Moreover, pushing the button for more than two seconds can easily change the stored memory.
3. Compact in size
We made it compact in size, equivalent to 1/4 DIN, so that it can be installed in a position where the driver can easily operate in the driver's seat.
4. Installed in a wide range of vehicles
In the future, we will develop shock absorbers which will be equipped with the EDFC. There are some vehicle types, however, for which the EDFC cannot be installed due to problems such as narrow clearance. As for shock absorbers already purchased by customers previously, we will confirm the installation.>
5. Reasonable Price
Sales price of $380 (list price).
We realized a reasonable sales price.
Function of EDFC
1. Damping force control function (16 levels / 32 levels)
Our damping-force-control-type shock absorbers normally have a built in damping force control function for 16 levels. This function controls the damping force by adjusting the rate of oil flow in the bypass through raising and lowering the damping force control needle built in piston rod for 16 levels. In the EDFC, this function is performed by a stepping motor installed on the top of piston rod, realizing a 16-level control, the same as in the manual control. Moreover, the operation by the controller with a decreased rotation angle has realized a finer adjustment of a 32-level mode in the same control range. The damping force for the front and rear wheels can be separately controlled, and the right and left wheels are simultaneously controlled.
2. Damping force level maintaining function
An EDFC switch is connected with the key position of the vehicle, the same as in general car audio components. If the EDFC power switch is continuously turned on, the EDFC can store in memory the click position setting when the driver gets out of the car and the key switch is turned off. Thus, when the engine is restarted, he/she can drive using the same setting. All memory contents are deleted when the EDFC power switch is turned off. The electric current to maintain memory is as slight as the current necessary for a standard equipment clock, and there is little possibility of a dead battery.
4. Damping force level memory function
It is equipped with a function to store in memory three settings of the damping force. The level setting in memory can be maintained even if the engine is turned off. The memory contents can be recalled with the touch of a button. Moreover, the stored memory contents can be easily changed by pushing the button for more than two seconds.
5. Damping force level resetting function
After the EDFC is installed, the driver will put it into a return-to-origin mode by rotating the motor in the clockwise direction when the power is turned on. With this operation, the controller can recognize the origin of the damping force control needle. The EDFC is equipped with a function to execute the return-to-origin mode compulsorily in the following occasions: in the case of installation or detachment of the EDFC, or when the control level is changed from 16-level to 32-level, or when the level displayed is different from the actual one due to external and mechanical reasons. This operation is not necessary in the normal driving, however. Turning on the main power again after turning it off can reset the damping force level. At this time, the memory contents are also reset.
6. Self-checking/warning function
In the case where the EDFC does not function correctly (due to an overcurrent or detached wires, etc.), all three memory buttons will blink red with an alarm sound and an error indication displayed, and the driver can confirm the position of the malfunctioning motor on the screen.
7. Volume/brightness control function
The beep sound volume while operating the EDFC can be set at three levels and can also be put into a silent mode. It is also possible to adjust the brightness of the display at three levels. This adjustment is connected with the power source for lamps, and it functions when the dimmer function is in operation at night.
8. Mis-operation preventive function
The EDFC is equipped with a lock mode, which prevents mis-operation. The 'key' mark is displayed and all operations become impossible including turning the power on and off. It is useful when the driver allows another driver to drive an EDFC-equipped vehicle. |
|
TEIN S.TECH Spring is an excellent step towards suspension tuning.
They offer approximately a 1.5 inch drop for a more aggressive appearance. Comes with a 1 year limited warranty.
Spring length is guaranteed not to sag more than 5mm and to be clear of any manufacture defects (see limited warranty for more details).
* One year limited warranty.
* High-grade material adapted to improve guaranteed satisfaction.
* Rubber spring protector sheet to prevent noise (most applications). |
|
TEIN Type CS damper was designed to give comfort to sophisticated drivers.
We adapted a hard rubber upper mount for noise proofing and mono-tube type shell case to heighten road holding.
* Improved ride comfort over original shock absorbers.
* A hard rubber upper mount is used for noise proofing.
* 16 levels of damping force adjustment (compression and rebound together).
* Ride height adjustable.
* A mono-tube design and increased shell case diameter allow for 30% more oil capacity,
as compared to OEM shock absorber, to handle the upsizing of wheel with lower profile tires.
* Available for overhaul.
Contents of damper kit
Adjustable shock absorber x4, Main spring x4,
Lower spring seat x4, Seat lock x4, Thrust washer x4,
Bump rubber x4,Dust cover x4, Rubber upper mount x4,
Height Gauge, Instruction manual,
Damping force adjust tool, Hook Spanner x2 |
Contents of damper kit
Height Adjustable shock absorber x4, Main spring x4
Lower spring Seat x4,Spring Seat lock x12
Bump rubber x4, Dust cover x4
Hook spanner x2, Instruction manual
*Strut suspension comes with upper spring seat.
Cool style coilover kit for Mini Van & Wagon.
Type WAGON is the coilover kit for recreational veicle and it provides comfort & fine driving stability even if you use upsizing wheels.Adopted single spring, it prevents a noise due to contact each spring wire.
Type WAGON has indicated, how did you get custom dress-ups more different than others. |
|
TEIN Type RA has been designed for advanced circuit racing and street use for experienced drivers.
It incorporates a newly designed mono-tube structure, which allows for maximum road handling and driving stability for all type of situations.
This product has been developed from a huge background of TEIN motor sports activities (such as the World Rally Championship,
N1 and endurance racing).
* Mono-tube design for maximum performance.
* Constructed of A7050 aluminum for lightweight (on certain applications).
* Strut type suspension has an inverted steel shock absorber for durability.
* 16 levels of damping force adjustment (compression and rebound together).
* Ride height adjustable.
* Exclusive designed pillow ball upper mount for optimize performance.
* Available for overhaul.
Contents of damper kit
Adjustable Damper X 4, Main spring X 4
Sub spring X 4, Lower spring seat X 4
Spacer spring seat X 4, Thrust washer X 4
Bump rubber X 4, Duster boots X 4, Pillow upper mount X 4
Height measuring gauge, Instruction manual
Damping effect adjusting tool |
|
TEIN Type RE is like the Type RA, but with an added full-length adjustment system.
Ride height is adjustable without changing the preload of spring.
This is the special feature of the full-length adjustment system due to threads on the lower bracket. The Type RE has a wide range for setting the stroke and length of the shock.
It is possible to set up this suspension for various road, weather, or track conditions while maintaining optimal suspension stroke.
* Mono-tube design for maximum performance.
* Full-length adjustment and height adjustment for separate setting of the
height and spring preload.
* 16 levels of damping force adjustment (compression and rebound together).
* Inverted shock structure for more horizontal stability for strut suspension.
* Available for overhaul.
Contents of damper kit
Full length Adjustable shock absorber x4, Main spring x4
Lower spring Seat x4,Spring Seat lock x8
Bump rubber x4, Dust cover x4, Pillow ball upper mount x4
Hook spanner x2, Instruction manual |
|
Type RS damper has the advantage over the RA and RE with its damping force adjustment feature.
With separate compression and rebound adjustment (16 levels X 16 levels), this allows the driver to set up the suspension damping force to meet any track conditions.
Furthermore, wishbone suspension and multi-link suspension have a reserve oil tank for larger oil capacity.
Strut type dampers are designed with inverted shocks for more horizontal stability.
* Mono-tube design for maximum performance.
* Compression and rebound damping force is adjustable separately (16 levels X 16 levels).
* Extra reserve oil tank for larger oil capacity for wishbone and multi-link suspension.
* Inverted structure for more horizontal stability for strut type suspension.
* Exclusively designed pillow ball upper mounts for optimize performance.
* Available for overhaul.
Contents of damper kit
Individual Comp/Rebump Adjustable shock absorber x4
Main spring x4, Lower spring Seat x4,Spring Seat lock x4
Bump rubber x4, Dust cover x4, Pillow ball upper mount x4
Hook spanner x2, Instruction manual |
|
TEIN Type HE damper has been designed for drifting performance.
It has a specific damping force and spring rate to optimize an easy control. It has also adapted a full length adjustable height system for a wide range of height set ups. These combined features improve the drifting experience. The Type HE is for the driver who is seeking a complete drifting suspension.
* Specified damping force and spring rate set up for drifting.
* Full-length adjustment and height adjustment for separate setting of the height and spring preload.
* 16 levels of damping force adjustability
(compression and rebound together).
* Available for overhaul.
Contents of damper kit
Full length Adjustable shock absorber x4
Main spring x4, Lower spring Seat x4,Spring Seat lock x8
Bump rubber x4, Dust cover x4, Pillow ball upper mount x4
Hook spanner x2, Instruction manual |
|
|
|
|
|
